Emergency Procedures

Electrical Fire & Smoke Behind Instrument Panel

FAA Ref: FAA-S-ACS-6C Area IX Task C (Systems and Equipment Malfunctions)

Scenario & Physics Summary

Immediate electrical master cutoff, cabin air isolation, fire extinguisher discharge, and visual flight recovery.

Interactive 3D Visual Plates & Scenario Media

Electrical Fire & Smoke Behind Instrument Panel Plate 1

Plate 1: Electrical Fire & Smoke Behind Instrument Panel

Electrical Fire & Smoke Behind Instrument Panel Plate 2

Plate 2: Electrical Fire & Smoke Behind Instrument Panel

Electrical Fire & Smoke Behind Instrument Panel Plate 3

Plate 3: Electrical Fire & Smoke Behind Instrument Panel

Electrical Fire & Smoke Behind Instrument Panel Plate 4

Plate 4: Electrical Fire & Smoke Behind Instrument Panel

Aerodynamic & Operational Physics

Electrical fires produce acrid black insulation smoke, blinding pilot vision and causing toxic fume inhalation.
Immediate action: Master Switch OFF, Cabin Heat/Air OFF, Vents OPEN (if smoke clears) or CLOSED (to starve oxygen).
Discharge Halon/Dry Chemical extinguisher near base of smoke. Land at nearest suitable airfield immediately.

FAA Exam Gotcha Alert

Exam Trap: Turning off Master Switch disables electric flight instruments, flaps, and turn coordinator. Fly by standby instruments or visual horizon.
